Complete Forks

RRH

Top Range

RRH concentrates the adjustment controls at the top for easier and faster tuning.

Unbroken masses are lightened and with them the weight total. The foot coupling design, gives a better structure by better discharging forces on the stem for better smoothness.
The top cap has spring preload, extension and compression adjustments.

Compatibility Check:

Riding Precision

The greater rigidity and smoothness of the fork provides excellent driving feeling to the rider.

Stability

Front axle, great hydraulic control allows driving maneuvers to the limit.

Grip

Thanks to the immediate hydraulic control.

Uniform

Wear of the tyres.

LC

Light Components:
This product has a high percentage of special light alloys and details optimised in weight, with the aim of achieving the maximum lightness possible.

RRH – SBK

TOP RANGE

Disc Brake Ø (mm)320320330330
Outer Tubes Ø (mm)52/5852/5852/5852/58
Length (mm)750780750 mm780 mm
Part NumberFC031RRH02FC032RRH02FC032RRH02FC033RRH02
For the final set-up, the feedback data of the participating teams at the WSBK, WEC, BSB, CIV, CEV, IDM, ASBK World Championship were used.

RRH – MOTO2

TOP RANGE

Outer Tubes Ø (mm)51/56
Length (mm)750
Part NumberFC013RRH04
Our engineering developments led immediately to a World Championship Podium in Moto2.
The technology of the EBH cartridge combined with a lightweight and rigid structure has proven to be the best suspension solution in the market.

HDH – MOTO3

TOP RANGE

Outer Tubes Ø (mm)45/4845/48
Length (mm)640670
Part NumberFC015HDH24FC026HDH24
For this class we have created a new fork that encompasses the technology available.
ADJUSTMENTSRRH – SBK / Moto2HDH – Moto3
COMPRESSION24 clicks24 clicks
REBOUND24 clicks24 clicks
SPRING PRELOAD15mm – 15 turns12 mm – 6 turns
